| Kích thước | Part No. | Part No. | |||||||
|---|---|---|---|---|---|---|---|---|---|
| BRT2 | |||||||||
| D | d | h | nó có | HB | φD1 | C | Standard (A505) | (A567) | 19YF |
| 32 | 24 | 5 | 5.7 | 7.7 | 31 | 3.5 | CU2683Q2 | CU2683Q3 ※ | GN5727V0 |
| 40 | 30 | 6 | 7 | 10 | 39 | CU2684Q3 | CU2684Q5 | GN4794V0 | |
| 50 | 40 | 49 | CU2604Q3 | CU2604Q4 | GN4050V0 | ||||
| 55 | 45 | 54 | CU2697Q1 | GN4804V0 | |||||
| 60 | 50 | 59 | CU2696Q2 | CU2696Q3 | GN4335V0 | ||||
| 63 | 53 | 62 | CU2685Q0 | CU2685Q4 | GN4693V0 | ||||
| 65 | 55 | 64 | CU2930Q2 | CU2930Q3 | GN4810V0 | ||||
| 70 | 60 | 69 | CU2634Q2 | GN4676V0 | |||||
| 75 | 62 | 7.5 | 8.5 | 11.5 | 74 | 4.5 | CU2943Q2 | CU2943Q3 | GN5712V0 |
| 80 | 65 | 9 | 10 | 13 | 79 | CU2666Q2 | CU2666Q3 | GN4549V0 | |
| 71 | 6 | 7 | 10 | CU3238Q1 | GN4818V0 | ||||
| 85 | 70 | 9 | 10 | 13 | 84 | CU0977Q2 | CU0977Q3 | GN4876V0 | |
| 95 | 80 | 94 | CU2605Q2 | CU2605Q4 | GN5023V0 | ||||
| 100 | 85 | 98 | CU2669Q2 | CU2669Q3 | GN4687V0 | ||||
| 110 | 95 | 108 | CU2607Q2 | CU2607Q3 | GN4822V0 | ||||
| 115 | 100 | 113 | CU3241Q2 | GN4512V0 | |||||
| 125 | 110 | 123 | CU2670Q2 | GN4480V0 | |||||
| 125 | 112 | 8.5 | 9.5 | 12.5 | 123 | CU3492Q0 | GN4827V0 | ||
| 130 | 115 | 128 | CU2609Q2 | CU2609Q3 | GN4593V0 | ||||
| 140 | 125 | 9 | 10 | 13 | 138 | CU2647Q3 | CU2647Q2 | GN4481V0 | |
| 150 | 136 | 8.5 | 9.5 | 12.5 | 148 | CU3244Q1 | GN4830V0 | ||
| 160 | 145 | 9 | 10 | 13 | 158 | CU2687Q1 | GN4551V0 | ||
| 180 | 165 | 14 | 178 | CU2688Q1 | GN4836V0 | ||||
| 200 | 180 | 12 | 13 | 17 | 198 | 5.5 | CU1539Q1 | CU1539Q2 | GN4470V0 |
| 224 | 204 | 222 | CU3491Q0 | GN4842V0 | |||||
| 250 | 230 | 248 | CU2691Q2 | CU2691Q3 | GN4635V0 | ||||
